| Ref |
Part Number |
Description |
Qty Req |
|
| 1 |
06451-NX4-860 |
SEAL SET, PISTON (34mm) |
1 |
Buy Now! |
|
2
|
06452-NX4-860 |
SEAL SET, PISTON (30mm) |
1 | Buy Now! |
| 3 |
06455-NX4-860
|
PAD SET, FRONT BRAKE (NISSIN) |
1 |
Buy Now! |
| 4 |
43352-568-003 |
SCREW, BLEEDER |
1 |
Buy Now! |
|
5
|
43353-461-771 |
CAP, BLEEDER |
1 |
Buy Now! |
| 6 |
43503-KS6-701 |
FITTING, CONNECTOR |
1 |
Buy Now! |
| 7 |
43516-HA2-000 |
RUBBER, OIL CUP MOUNT |
1 |
Buy Now! |
| 8 |
43517-KS6-701 |
CIRCLIP, REAR MASTER CYLINDER |
1 |
Buy Now! |
| 9 |
45100-NX4-861 |
CALIPER ASSY, RIGHT FRONT |
1 |
Buy Now! |
| 10 |
45103-MR7-006 |
SEAL, JOINT |
1 | Buy Now! |
| 11 |
45106-NX4-860 |
SPRING, BRAKE PAD |
1 |
Buy Now! |
| 12 |
45107-NX4-860 |
PISTON B, BRAKE CALIPER (34mm) |
2 |
Buy Now! |
| 13 |
45117-MR7-006 |
PISTON A, BRAKE CALIPER (30mm) |
2 |
Buy Now! |
| 14 |
45125-NX4-861 |
HOSE, FRONT BRAKE |
1 |
Buy Now! |
| 15 |
45150-NX4-860 |
CALIPER SUB ASSY, RIGHT FRONT |
1 |
Buy Now! |
| 16 |
45215-NX4-860 |
PIN, HANGER |
1 |
Buy Now! |
| 17 |
45500-NX4-861 |
MASTER CYLINDER ASSY, FRONT BRAKE |
1 |
Buy Now! |
| 18 |
45504-410-003 |
BOOT COMP, DUST |
1 |
Buy Now! |
| 19 |
45511-KV3-016 |
OIL CUP COMP |
1 |
Buy Now! |
| 20 |
45512-NX4-861 |
HOSE, MASTER CYLINDER OIL CUP (6x9x195) |
1 |
Buy Now! |
| 21 |
45513-KV3-006 |
CAP, MASTER CYLINDER OIL CUP |
1 |
Buy Now! |
| 22 |
45514-KV3-006 |
CLAMP, MASTER CYLINDER OIL HOSE |
2 |
Buy Now! |
| 23 |
45517-166-006 |
HOLDER, FRONT MASTER CYLINDER |
1 |
Buy Now! |
| 24 |
45518-KV3-006 |
PLATE, DIAPHRAGM |
1 |
Buy Now! |
| 25 |
45520-KV3-006 |
DIAPHRAGM |
1 |
Buy Now! |
| 26 |
45530-471-831 |
CYLINDER SET, MASTER |
1 |
Buy Now! |
| 27 |
45530-NF4-650 |
BOLT ASSY, OIL BLEEDER |
1 |
Buy Now! |
| 28 |
45550-NX4-861 |
STAY, FRONT M/C CUP |
1 |
Buy Now! |
| 29 |
50324-425-010 |
COLLAR (6.3x13) |
1 |
Buy Now! |
| 30 |
53170-MW0-006 |
LEVER, FRONT BRAKE |
1 |
Buy Now! |
| 31 |
53171-MW0-006 |
KNOCKER,M/C |
1 |
Buy Now! |
| 32 |
53172-KV0-006 |
ADJUSTER, RIGHT HANDLE LEVER |
1 |
Buy Now! |
| 33 |
53175-MW0-006 |
LEVER COMP, FRONT BRAKE |
1 |
Buy Now! |
| 34 |
53177-KV0-006 |
BOLT, LEVER SOCKET (5x5) |
1 |
Buy Now! |
| 35 |
53179-KV0-006 |
JOINT, LEVER |
1 |
Buy Now! |
| 36 |
53180-KV0-006 |
BOLT, ADJUSTING |
1 |
Buy Now! |
| 37 |
53181-KV0-006 |
SPRING, HANDLE LEVER |
1 |
Buy Now! |
| 38 |
90107-NX4-860 |
BOLT, TORX 8x38 |
4 |
Buy Now! |
| 39 |
90114-MA5-671 |
BOLT, HANDLE LEVER |
1 |
Buy Now! |
| 40 |
90131-NX4-860 |
BOLT, FLANGE 10x75 |
2 |
Buy Now! |
| 41 |
90145-MS9-612 |
OIL BOLT 10x22 |
1 |
Buy Now! |
| 42 |
90145-NF4-650 |
BOLT, OIL BLEEDER |
1 |
Buy Now! |
| 43 |
90301-MG3-000 |
U-NUT, 6mm |
1 |
Buy Now! |
| 44 |
90302-NX5-000 |
U-NUT, HEX (6mm) |
1 |
Buy Now! |
| 45 |
90473-147-000 |
WASHER 6x16 |
1 |
Buy Now! |
| 46 |
90601-ZE1-000 |
WASHER, DRAIN PLUG (10mm) |
4 |
Buy Now! |
| 47 |
90651-MA5-671 |
CIRCLIP |
1 |
Buy Now! |
| 48 |
90701-NX4-860 |
PIN, LOCK |
1 |
Buy Now! |
| 49 |
91212-422-006 |
O-RING (14.8x2.4) |
1 |
Buy Now! |
| 50 |
93600-04050-1G |
SCREW, FLAT HEAD (4x50) |
2 |
Buy Now! |
| 51 |
96001-06025-00 |
BOLT, FLANGE (6x25) |
2 |
Buy Now! |
| 52 |
96300-06012-07 |
BOLT, FLANGE (6x12) |
1 |
Buy Now! |
| 53 |
96300-06028-07 |
BOLT, FLANGE DR 6x28 |
1 |
Buy Now! |
|
|
|
